Terminal Block Relay, Pluggable SPDT 230Vac/dc Relay, 250Vac Output, Din Rail Mount, UL Listed,

ASI X766847, Type CWRE7-0847, Terminal block relay with a pluggable SPDT relay that has a 230Vac/dc coil and a contact rating of 6A, 250Vac. This DIN rail terminal block relay is ideal as an isolation relay or interposing relay and saves space in your equipment due to the 6mm width. Features of this terminal block relay include screw clamp wire terminations, a locking actuator to hold in place and remove the 230Vac/dc relay and a LED for visual indication. You can compare this 230Vac/dc terminal block relay to Phoenix type PLC-RSC-230UC/21, part number 2966207. The terminal block relay base in combination with the 230Vac/dc pluggable relay are UL508 Listed and replacement relays are available. The push in jumpers can be used to save time when inserting a jumper from one 230Vac/dc relay terminal block to another. Since this industrial relay mounts on the standard 35mm DIN rail installation with other DIN rail mounted components is quick and easy. To ensure wiring is correct each 230Vac/dc terminal block relay base has the wiring diagram printed on the side. Snap in markers are available to identify each terminal block relay in your panel. The ASIX766847 terminal block relay is cULus 508 Listed for use in both the USA and Canada.
