Motor Reversing Switch, 3 Phase AC Motor Reversing Switch, With Spring Return to Zero, Reversing Drum Switch For Up To 20 HP, Rear Panel Mount

The ASI C0320013R is a rear panel mounted motor reversing switch or reversing drum switch for 3 phase motors up to 20 horsepower. This 3 phase motor reversing switch features a spring return to zero upon operation. The ASI C0320013R spring return reversing drum switch has 3 poles and can be used with 208vac, 480vac, and 600vac 3 phase motors. This 3 phase motor reversing switch features self cleaning contacts, silver alloy plating and a UL94V0 thermoplastic housing. With UL508 listing of 600 Vac, 32A this forward and reverse motor switch is ideal for three phase motors ranging from 7.5 HP to 20 HP based on voltage. The C0320013R ac motor reversing switch is a compact design to save space, the wire connections are shock hazard proof and information on wiring and identification are laser engraved into the housing. The reversing drum switch wiring diagram can be found under the picture of the drum switch. A wide range of NEMA 4X handles and operators are available for the motor reversing switches including a lockable handle capable of accepting padlocks. Complete drum switch enclosures are available upon request which would include your exact size reversing motor switch mounted in a high impact thermoplastic enclosure and operating handle.
